Water-Cooled Water Chiller / CW-5000 CW-5200

Type
Regular price
$699.30
Regular price
Sale price
$699.30
Shipping calculated at checkout.

    Description

    Water-cooled water chiller uses external circulating water working with the internal system for efficient refrigeration, smaller size with larger cooling capacity.

    Application

    Water Chiller is for water circulation cooling, especially for acrylic bending machine,
    acrylic bender and CO laser machine. When the acrylic bending machine is working, it
    need to put a water pump into a tank to achieving the aim of water circulation cooling,
    the the temperatture up to °C, it need to change the water, While the water chiller could
    slove this problem could ensure constant working, do not need change water.

    Parameters

    Model

    CW3000

    CW5000

    CW5200

    Voltage

    220V/110V

    220V/110V

    220V/110V

    Compressor

    No

    Yes

    Yes

    Refrigeration capacity

    50w/°0

    800W

    1750W

    Pump power

    30W

    30W

    55W

    Max.lift

    10M

    10M

    12M

    Max.flow

    10L/min

    10L/min

    12L/min

    Tank capacity

    8L

    8L

    8L

    Inlet and outlet

    10mm brabed connector, 8/10/12mm speedy connector

    10mm brabed connector, 8/10/12mm speedy connector

    10mm brabed connector, 8/10/12mm speedy connector

    N.W

    9.5kg

    21.8kg

    26.4kg

    G.W

    11.5kg

    24.6kg

    28.8kg

    Dimension

    47*27*37cm

    58*29*47cm

    58*29*47cm

    Package dimension

    56*36*47cm

    70*43*58cm

    70*43*58cm
