HP DesignJet T630 36" Large-Format Wireless Plotter 2025 Edition - New (5HB11D#B1K)
- Regular price
-
$2,025.00 - Regular price
-
- Sale price
-
$2,025.00
Couldn't load pickup availability
Tech Specs
Description
The world's smallest wide-format printer with a built-in stand, is designed to fit your office, budget, and the way you work. Print multi-size projects with ease. Print your A1 plot as fast as 30 seconds. 1 GB memory.
INTUITIVE—Easy, effortless printing
Print multi-size A3/B and A1/D or A0/E projects automatically, without manually switching the media source. Print multi-size A4/A to A0/E projects automatically, without manually switching the media source. Print your jobs and manage your plotter virtually anywhere, anytime with the HP app.
RESPONSIBLY DESIGNED—Reduce energy and plastic use
Save 65% energy with the printer on/off auto scheduler and enjoy efficient ink maintenance routines. Use up to 95% less ink for routine maintenance vs competitor and get up to 100 extra A1/D pages per month. Made with at least 40% recycled plastic and the first HP large format printer containing recycled metal.
OPTIMIZED—Fits the way you work
Avoid waiting by the printer with high-speed printing as fast as 30 seconds per A1/D plot. Avoid waiting by the printer with printing as fast as 30 seconds per A1/D plot. Protect your printer from cyberthreats with HP Wolf Essential Security.
Technical Specifications
| Accessories | B3Q37A HP DesignJet 36-in Spindle |
| Acoustic power emissions (active, printing) | 5.8 B(A) (operating), <3.4 B(A) (idle) |
| Acoustic pressure emissions | 42 dB(A) (operating), <16 dB(A) (idle) |
| Connectivity, standard | Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/RED Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class B product: Korea (KCC) |
| Energy star certified | Yes |
| Environmental certification | ENERGY STAR; WEEE; EU RoHS; EAEU RoHS; REACH; ErP; EPEAT Climate+ Gold; UL Ecologo |
| Finished output handling | Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter |
| Functions | |
| High capacity of page yield (color) | 20 ml of ink yields 101 A1/D pages, taking into account maintenance routines[2] |
| Ink drop | 5.5 pl (C, M, Y); 12 pl (K) |
| Ink types | Dye-based (C, M, Y); pigment-based (K) |
| Internal Storage | None |
| Line accuracy | ±0.1%[3] |
| Maximum optical density (black) | 8 L* min/2.10 D[4] |
| Media sizes standard (sheets, rolls) | 11 to 36 in |
| Media sizes supported | Auto sheet feeder: A, B; manual feed: A, B, C, D, E |
| Media sizes, custom | Auto sheet feeder: 8.3 x 11 to 13 x 19 in; manual feed: 8.3 x 11 to 36 x 74.7 in |
| Media thickness | Up to 11.8 mil |
| Media types | Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene) |
| Media width, maximum | 36 in |
| Memory | 1 GB |
| Model size | 36 in |
| Non-Operating Humidity Range | 0 to 95% RH |
| Non-printable area (cut-sheet) | 0.2 x 0.2 x 0.2 x 0.7 in (manual feed); 0.2 x 0.2 x 0.2 x 0.2 in (input tray) |
| Non-printable area (roll media) | 0.2 x 0.2 x 0.2 x 0.2 in |
| Operating altitude | Up to 9843 ft |
| Operating humidity range | 20 to 80% RH |
| Operating temperature range | 41 to 104ºF |
| Post consumer recycled plastic in hardware by weight of plastic | 40% |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max |
| Power consumption | <35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby) |
| Print Cartridge/Bottle, Color(s) | Cyan, magenta, yellow, black |
| Print Cartridges/Bottle, Number | 4 (C, M, Y, K) |
| Print head nozzles | 1376 |
| Print heads | 1 (cyan, magenta, yellow, black) |
| Print languages | HP-GL/2, HP-RTL, CALS G4, JPEG, URF |
| Print multi-size files in one click | Yes |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Print speed | 30 sec/page on D, 76 D prints per hour[1] |
| Print Technology | Ink |
| Print technology | HP Thermal Inkjet |
| Printer drivers included | Raster driver for macOS and Windows, HP-GL/2 driver for Windows, HP Click Driver for Windows 11 |
| Printing path | HP Click App, HP Click Driver, HP app, Windows and MacOS printer drivers, HP-GL/2 driver for Windows, Apple AirPrint, Android Default Print Service, Printing support for ChromeOS, Email printing |
| Recommended media | Q1396A HP Universal Bond Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 45.7 m (24 in x 150 ft);C6019B HP Coated Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 45.7 m (24 in x 150 ft);C6029C HP Heavyweight Coated Paper (FSC® certified)[5] (recyclable)[6] 610 mm x 30.5 m (24 in x 100 ft) |
| Registration required | No |
| Remote print enabled | Yes |
| Roll external diameter | 3.9 in |
| Roll maximum input | 1 |
| Roll maximum weight | 13.6 lb |
| Safety | USA and Canada (CSA certified); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia, Belarus, Khazakstan (EAC); Ukraine (UA); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Mexico (NYCE) |
| Security features | HP Wolf Essential Security: Secure boot with HW root of trust; Firmware Code Signature Validation; Automatic FW Updates; HTTPS Redirect enabled by default; SNMPv1/2 read-only by default; SNMPv3 disabled by default; Write-protected memory; HP Cartridge Security; Unique password; Disable USB ports; TLS 1.2; 802.1x; IPv4 & IPv6 Compatibility; CA/JD Compatibility |
| Software included | HP Click App for Windows and macOS, HP Click Driver for Windows 11, HP app for Windows, macOS, Android and iOS |
| Storage temperature range | -13 to 131ºF |
| Supported Primary Applications | Line drawings; Presentations; Renderings |
| Theoretical minimum line width | 0.0008 in |
| What's in the box | HP DesignJet T630 36-in Printer, printer stand, automatic sheet feeder, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord |
