Tech Specs
Specifications
| Printing Technology | FINE: Full-Photolithography Nozzle Engineering |
| Head Configuration | 12-Channel Integrated Type |
| Nozzle Configuration | 1,536 Nozzles x 12 Channels: 18,432 Total |
| Minimum Droplet Size | 4 Picoliters per Color |
| Maximum Print Resolution | Up to 2400 x 1200 dpi |
| Ink Information |
Type: Pigment-Based GP Ink Technology PFI-2100 (160 ml): FP, R, O, G, V, PBK, MBK, C, M, Y, GY PFI-2300 (330 ml):FP, R, O, G, V, PBK, MBK, C, M, Y, GY PFI-2700 (700 ml):FP, R, O, G, V, PBK, MBK, C, M, Y, GY |
| Print Head | PF-10 (1) |
| Colors |
Fluorescent Pink, Red, Orange, Green, Violet, Photo Black, Matte Black, Cyan, Magenta, Yellow, Gray |
| Ink Tank Shipped with Printer |
10 Colors + Fluorescent Pink 330 ml (MBK); 160 ml (All Other Colors) |
| Hard Disk Capacity | 500 GB |
| Printer Memory | 3 GB |
| Printer Stand | Standard |
| Display | 4.3" Color LCD Touch-screen |
| Size / Weight (with basket open) | 46” (H) x 44” (W) x 39” (D)/Approx. 225 lb |
| Media Feed | Front-Loading Roll Feed: One Roll, Front Output |
| Media Width | 6” – 24” (Cut-Sheet and Roll) |
| Minimum Media Length | 8" |
| Maximum Print Length* |
59' (Roll Paper) 84" (Cut-Sheet) |
| Borderless Printing Widths |
Custom Roll Width 6” – 24” with Micro Margin Technology |
| Media Thickness | .07 mm – .8 mm |
| Media Core Sizes | 2" or 3" Core (with Supplied Adaptor) |
| Printable Margins |
Roll Paper: Top: 20 mm; Bottom: 3 mm; Side: 3 mm Cut-Sheet: Top: 20 mm; Bottom: 20 mm; Side: 3 mm |
| Maximum Media Roll (Outer Dia.) | 6.7" (170 mm) |
| Interfaces |
Hi-Speed USB, 10/100/1000Base-T/TX, Wireless LAN (IEEE 802.11 b/g/n)** |
| Recommended Operating Environment■ |
Temperature: 59° – 86° F (15° – 30° C) Humidity: 10 – 80% (No Condensation) |
| Power Supply | AC 100–240 V (50-60 Hz) |
| Power Consumption |
Maximum: 84 W or Less Standby: 2.0 W or Less Power Off: 0.3 W or Less |
|
Software |
PosterArtist Lite (PC Only), Professional Print & Layout, ■ ■ Free Layout plus (PC Only), Printer Driver Extra Kit (PC Only), Accounting Manager, Media Configuration Tool, Direct Print Plus (PC Only), Device Management Console, Quick Utility Toolbox, Canon PRINT Inkjet/SELPHY, Canon Print Service (Android Only), Easy-PhotoPrint Editor |
| Optional Software | PosterArtist (PC Only) |
| OS Compatibility |
32-bit: Windows 7/8.1/10 64-bit: Windows 7, Windows 8.1, Windows 10, Windows Server 2008 R2, Windows Server 2012/2012R, Windows Server 2016, Windows Server 2019, Mac OS X 10.12.6 or Later |
| User-Replaceable Items |
Print Head (PF-10) Maintenance Cartridge (MC-30) Rotary Cutter (CT-07) |
| PANTONE Calibrated |
PANTONE PASTELS & NEONS GUIDE Coated: 97% when using Photo Paper Pro Premium Platinum with imagePROGRAF printer driver at [Poster/Photo (Fluorescent)] [Highest] (600dpi) PANTONE FORMULA GUIDE Solid Coated: 99% when using Photo Paper Pro Premium Platinum with imagePROGRAF printer driver at [Poster/Photo (Fluorescent)] [Highest] 600 dpi |
| Options |
Multifunction Roll System (RU-43) Roll Holder Set (RH2-46) |
