CALCA 18in x 24in DTF Oven With Temperature Control Pro DTF Oven Curing Transfer Film DTF Sheet Drawer Model

Original price $499.00 - Original price $499.00
Original price
$499.00
$499.00 - $499.00
Current price $499.00

CALCA 18in x 24in DTF Oven With Temperature Control Pro DTF Oven Curing transfer film DTF Sheet Drawer Model

DTF curing oven for baking transfer sheets that are freshly powdered. Fit sheets up to 18in x 24in.
Settings are Preset!Tested with CALCA DTF Supplies.Small footprints and easy to operate.

Specifications:
Cures film up to 18in x 24in(460mm x 610mm)(drawer model)
Control:temperature&time setup,PID control
Supply:110V,2400W,21.8A/220V,2400W,10.9A
Lamps number: 6pcs
Curing temperature up to 160°C (320°F)
Controllable digital timer:180–300s
Suggested temperature is 100-170°C (212-338°F) (The specific temperature depends on the melting point of the powder.)
Suggested time is 210s-300s.(the specific time depends on the melting condition of the powder.)

Dimension: 36.2in x 22.6in x 6.5in (920mm x 573mm x 165mm)
Net weight:44lbs(20kg)
Packing Size:38.2in x 24in x 8.3in(970mm x 610mm x 210mm)
Gross Weight: 49.5lbs(22.5kg)
We recommend using this in conjunction with a fume extractor or outside venting. Fumes may be harmful if inhaled.

Feature:
1.Second generation design ,more scientific structure ,more accurate temperature control ,full width drying and curing without dead corner ,perfect curing fusion effect.
2.Automatic timing ,arrival buzzer and LED alarm.
3.Suitable for 24in DTF printing,ink&powder fuse curing.
