24" MULTI-MARK with Professional Sensor Head Vinyl Cutter

Options
$601.00
$601.00
Shipping calculated at checkout.
    24" MULTI-MARK with Professional Sensor Head Vinyl Cutter

    Tech Specs

    Features:

    1. High strength aluminum alloy frame, elegant appearance with streamline design
    2. 10bd quieter than ordinary cutting plotter, speeds reach 800mm / s
    3. Multi-mark point with subsection supported to guarantee long media scan precision
    4. Professional sensor head support more glossy material contour cut scan

    Specification:

    Model:  A-S24
    Automatically Contour Cutting: Standard
    Interface: USB2.0, RS232C
    Max Cutting Speed: 800mm / s
    Driver: 2.5A high speed stepper motor, 16 micro step sub driving driver
    Pressure: 50g-800g (160grade)
    Display: 4 x 8 High Resolution LCD
    Power Supply: AC90-240V / 50Hz-60Hz
    STAND: Optional (Please contact customer service)
    Hop-pocket: Optional (Please contact customer service)
    Acceptable Media Width: 852mm
    Max Cutting Width: 680mm

    Specifications

    Model: A-S24
    Automatically Contour Cutting: Standard
    Interface: USB2.0, RS232C
    Max Cutting Speed: 800mm / s
    Driver: 2.5A high speed stepper motor, 16 micro step sub driving driver
    Pressure: 50g-800g (160grade)
    Display: 4 x 8 High Resolution LCD
    Power Supply: AC90-240V / 50Hz-60Hz
    STAND: No
    Hop-pocket: No
    Acceptable Media Width: 852mm
    Max Cutting Width: 680mm
    Machine Size: 890 mm x 265 mm x 270mm (35in x 10.4in x 10.6in)
    Net Weight: 12kg (26.57lbs)
    Shipping Dimensions: 1127 mm x 370 mm x 370mm (44.4in x 14.5in x 14.6in)
    Gross Weight: 16kg (35.3lbs)
