| Accessories |
P7V13A HP Pro Scanner Output Delivery Tray |
| Acoustic power emissions (active, printing) |
6.4 B(A) (operating), <3.3 B(A) (idle), <3.3 B(A) (sleep) |
| Acoustic pressure emissions |
62 dB(A) (operating), <30 dB(A) (idle), <30 dB(A) (sleep) |
| Bit depth |
48-bit/16-bit |
| Compatibility |
HP DesignJet T920 Printer series; HP DesignJet T930 Printer series; HP DesignJet T940 Printer; HP DesignJet T790 Printer series; HP DesignJet T795 Printer; HP DesignJet T1300 PostScript® Printer; HP DesignJet T1500 Printer series; HP DesignJet T1530 Printer series; HP DesignJet T1600 Printer; HP DesignJet T1700 Printer series; HP DesignJet T2500 Multifunction Printer series; HP DesignJet T2530 Multifunction Printer series; HP DesignJet T2600 Multifunction Printer series; HP DesignJet T3500 Production Multifunction Printer; HP DesignJet XL 3600 Multifunction Printer; HP PageWide XL 39x0, 4x00, 5x00, 6x00, 8x00 Printers; HP DesignJet Z6/Z9+ PostScript® Printer series; HP DesignJet Z6/Z9+ Pro Printer series; HP DesignJet Z5200 Photo Printer; HP DesignJet Z5400 PostScript® Printer; HP DesignJet Z5600 PostScript® Printer; HP DesignJet Z6610 Production Printer; HP DesignJet Z6810 Production Printer series |
| Connectivity, standard |
Dual Gigabit Ethernet (1000Base-T), SuperSpeed USB 3.0 |
| Copier settings |
Print mode, output size, paper type, copies, page order, collate, printer output destination (folder, stacker, bin), folding style selection (only available when folder accessory is available and supported by the HP large-format printer), paneling, tiling, nesting, reprint |
| Copies, maximum |
Unlimited |
| Eco benefit |
ENERGY STAR® qualified and EPEAT registered[1] |
| Eco footnote [01] |
[1] EPEAT registered where applicable. EPEAT registration varies by country. See http://www.epeat.net for registration status by country. |
| Electromagnetic compatibility |
Compliance for Class A ITE products: EU (EMC Directive), USA (FCC Rules), Canada (ICES), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP), Russia (EAC) |
| Energy star certified |
Yes |
| Enhanced scanning resolution |
9600 dpi |
| Environmental certification |
ENERGY STAR, WEEE, RoHS (EU, China, Korea, India), REACH, EPEAT |
| Finished output handling |
Straight-through scan paper path for sheet and cardboard originals. Face-up, front entry, rear exit, rewind to front, use document return guide for front-return. |
| Functions |
Copy, scan |
| Interface |
15.6" (396-mm) large touchscreen to preview and enhance images |
| Internal Storage |
500 GB |
| Linear scan speed |
Color: up to 6 in/sec; Grayscale: up to 13 in/sec[1] |
| Maximum Memory |
4 GB |
| Media thickness |
0.08 in |
| Media types |
Non-abrasive paper, sepia, blueprints, plastic, plastic laminate, foam board, cardboard, newspaper (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies) |
| Media width, maximum |
46 in |
| Memory |
4 GB |
| Model size |
44 in |
| Network ready |
Standard |
| Non-Operating Humidity Range |
0 to 95% RH |
| Operating humidity range |
20 to 80% RH |
| Operating temperature range |
41 to 95ºF |
| Power |
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max |
| Power consumption |
47 W (scanning), 32 W (ready), 1.8 W (sleep) |
| Printer drivers included |
Windows drivers for compatible HP PageWide XL and HP DesignJet Printers |
| Processor |
Intel Core i7 |
| Recycling statement |
Please recycle large-format printing hardware and printing supplies. Find out how at our website: http://www.hp.com/ecosolutions |
| Registration required |
No |
| Safety |
USA and Canada (UL certified), EU (LVD and EN 60950-1 compliant), Russia (EAC), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE), Korea (KC) |
| Scan accuracy |
0.1% ±1 pixel |
| Scan file format |
PDF, PDF/A, TIFF, JPEG, JPEG2000, DWF, multi-page PDF generation |
| Scan input modes |
File, email, USB, HDD, network folder, FTP, print |
| Scan resolution, optical |
1200 dpi |
| Scan size, maximum |
44 in |
| Scan size, minimum |
6 x 4.5 in |
| Scan speed footnote |
Monochrome scanning: A1/D image with black text graphics at 200 dpi; color scanning: A1/D fully-inked color image at 200 dpi, 24-bit RGB |
| Scanner type |
CIS scanning technology |
| Storage temperature range |
-13 to 131ºF |
| Supported Primary Applications |
Line drawings; Renderings; Presentations; Maps; Orthophotos |
