Printheads
|
Two inks in each printhead: gloss enhancer and gray, blue and green, magenta and yellow, light magenta and light cyan, photo black and light gray, and matte black and red
|
|
Ink cartridges
|
Cartridges containing 130 ml of ink: gloss enhancer, gray, blue, green, magenta, yellow, light magenta, light cyan, photo black, light gray, matte black, and red
|
|
|
Minimum
|
Maximum
|
|
Roll Width
|
18 inches (460 mm)
|
24-inch printer: 24 inches (609 mm)
44-inch printer: 44 inches (1118 mm)
|
|
Roll Length
|
|
300 feet (91.4 m)
|
|
Sheet Width
|
8.3 inches (210 mm, A4 Portrait)
|
24-inch printer: 24 inches (609 mm)
44-inch printer: 44 inches (1118 mm)
|
|
Sheet Length
|
11 inches (279 mm, Letter Portrait)
|
24-inch printer: 36 inches (915 mm)
44-inch printer: 66 inches (1676 mm)
|
|
Print Quality
|
Maximum detail
|
Extra passes
|
Rendering Resolution (dpi)
|
Printing Resolution (dpi)
|
|
Best
|
On
On
Off
Off
|
On
Off
On
Off
|
1200 × 1200
1200 × 1200
600 × 600
600 × 600
|
2400 × 1200 (glossy media only)*
1200 × 1200
600 × 600
600 × 600
|
|
Normal
|
On
Off
Off
|
600 × 600
600 × 600
300 × 300
|
600 × 600
600 × 600
300 × 300
|
|
|
Fast
|
On
Off
Off
|
600 × 600
600 × 600
300 × 300
|
600 × 600
600 × 600
300 × 300
|
* HP Premium ID Gloss, HP Premium ID Satin, HP Professional Satin Photo Paper, Photo Gloss, Photo Semigloss/Satin, HP Contract Proofing Gloss, HP Contract Proofing Satin, Proofing Gloss, Proofing Semigloss/Satin
|
Top right and left margins
|
5 mm = 0.2 inches
|
|
Bottom margin (trailing edge)
|
5 mm = 0.2 inches (roll)
17 mm = 0.67 inches (sheet)
|
|
±0.2% of the specified vector length or ±0.1 mm (whichever is greater) at 23°C (73°F), 50-60% relative humidity, on E/A0 printing material in Best or Normal mode with HP Matte Film roll feed.
|
|
HP Designjet Z2100 Photo Printer Series standard
|
HP-PCL3 GUI
|
|
HP Designjet Z2100 Photo Printer Series with HP-GL/2 upgrade
|
HP-GL/2 RTL
|
PHYSICAL SPECIFICATIONS
