Wide Image Solutions

Kyocera Inkjet Printhead / KJ4A-0300

$4,743.23
$4,743.23
Shipping calculated at checkout.
    Kyocera Inkjet Printhead / KJ4A-0300
    Kyocera Inkjet Printhead / KJ4A-0300
    Kyocera Inkjet Printhead / KJ4A-0300

    Tech Specs

    Description

    This original Kyocera KJ4A-0300 printhead is designed for high speed single-pass applications with printers using aqueous ink, multi-pass using UV inks. It is a 300dpi two colours printhead with a maximum drive frequency of 30kHz. It delivers high quality with a small drop volume of 4pl at 158 m/min by making use of 2,656 nozzles arranged across 112.35 mm wide print swathe. We recommend to change the head cables when installing a new printhead.

    Product Specifications

    • Ink Type:  UV ink
    • Dimensions: 200 × 36 × 61.4mm
    • Dry Weight: 540g
    • Total Nozzles: 2.656 (2x 1328)
    • Standard Resolution: 300 x 300dpi
    • Print Width: 112.35mm
    • Max. Drive Frequency: 30kHz
    • Drop Volume: 4, 6, 10 and 14pl
    • Max. Sprint Speed: 158m/min
    • Typical ink viscosity: 7.0-7.5 mPa

    Printer compatibility

    • Docan FR3210T
    • Docan H3000

    • Handtop HT2500UV HR8
    • Handtop HT3200
    • Handtop HT3200UV

    • Imprimo Titanium UV Flatbed

    • Polaroid T-REX

    • Vanguard VK300D-HS
