HP Latex 310 54" Printer - Specifications
Print speed, maximum
48 m²/hr - Billboard (2 pass); 16 m²/hr - Outdoor Plus (6 pass); 12 m²/hr - Indoor Quality (8 pass); 9.7 m²/hr - Indoor High Quality (10 pass); 6.1 m²/hr - Backlits, Textiles, and Canvas (16 pass); 4.9 m²/hr - High Saturation Textiles (20 pass)
Print quality color (best)
Up to 1200 x 1200 dpi
Print technology
HP Latex Printing Technologies
Print Cartridges/Bottle, Number
7 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer)
Print heads
6 (2 cyan/black, 2 magenta/yellow, 1 light cyan/light magenta, 1 HP Latex Optimizer)
Print repeatability
Average <= 1 dE2000, 95% of colors <= 2 dE2000
Finished output handling
Roll feed; take-up reel (optional)
Media types
Banners, self-adhesive vinyls, films, papers, wallcoverings, canvas, synthetics, (fabrics, mesh, textiles and any other porous materials require a liner)
Non-printable area (roll media)
0.2 x 0.2 x 0.2 x 0.2 in
Non-printable area (roll media)
5 x 5 x 5 x 5 mm
Media width, maximum
1371 mm
Roll maximum weight
25 kg
Roll external diameter
180 mm
Media thickness
Up to 19.7 mil
Dimensions (W x D x H)
2307 x 840 x 1380 mm 91 x 33 x 54 in
Package dimensions (W x D x H)
2541 x 760 x 1250 mm 100.1 x 30 x 49.3 in
Package weight
257.5 kg 568 lb
Operating temperature range
15 to 30ºC
Operating humidity range
20 to 80% RH (non-condensing)
Acoustic pressure emissions
54 dB(A)
Acoustic pressure emissions (standby)
38 dB(A)
Acoustic power emissions (active, printing)
7.2 B(A)
Acoustic power emissions (standby)
5.5 B(A)
Power consumption
2.2 kW (printing); 70 watts (ready); < 2.5 watts (sleep) Two power cords, single phase / two wires and PE
