CALCA 32in Compact DTF Powder Shaker and Dryer, Vertical Model

$5,599.00
$5,599.00
Shipping calculated at checkout.
    CALCA 32in Compact DTF Powder Shaker and Dryer, Vertical Model
    CALCA 32in Compact DTF Powder Shaker and Dryer, Vertical Model
    CALCA 32in Compact DTF Powder Shaker and Dryer, Vertical Model

    Tech Specs

    Description

    CALCA DTF powder shaker and dryer unit can handle up to 32in wide DTF film.
    With the advancement in DTF technology, there is no denying that DTF is taking the printing industry by storm. It is quickly becoming one of the most popular technologies for textile printing compared to traditional printing methods.
    This all in one dtf powder shaker unit takes over by evenly spreading, then melting the needed amount of adhesive material directly onto your printed image, saving time, effort, and cost.
    The vacuum absorption conveying platform secures the printing material to avoid bulging, run-offs, and media waste.
    This 32in dtf powder shaker is designed to fit the size of the Mimaki TXF150-75 DTF printer.

    Applicable Medium: Nylon, Chemical Fiber, Cotton, Leather, Swimsuit, Diving Suit, PVC, EVA, etc.

    Specifications:

    Model: DTF-PSM-ZD820
    CALCA Brand: USA registered
    Working Power Supply: AC220V, 50hz / 60hz, 1 phase.
    Current: 14A, 3000W
    Maximum Shake Powder Width: 800mm (31.5inches)
    Heating Element: 4pcs Quartz infrared heat drying tube
    Material Conveying Method: Take-Up Reel pulling type
    Rewinding Function: Automatic induction rewinding
    Heating and Drying Mode: Front guide plate heating, upper drying curing
    Cooling Mode: 4 fan air cooling (single row)
    Machine Size: 43.7in x 46.1in x 38in (1110mm x 1171mm x 964mm)
    Powder Shaker and Dryer Weight: 444.2lbs (201.5kg)
    Packaging Size: 34.3in x 51.2in x 43.8in (870mm x 1300mm x 1113mm)
    Gross Weight: 591lbs (268kg)

    Remarks:
    CALCA DTF powder shakers do not have automatic powder recycling function, in order to avoid hot melt powder moisture.

    Features:

    √ The DTF Powder Applicator with the capability of curing DTF film rolls up to 800mm wide.
    √ The winding system is added to make the media more tightly and neatly.
    √ Automatic Control Panel is Easy-to-use
    √ Infrared drying and heating improves and protects color reproduction.
    With the advancement in DTF technology, there is no denying that DTF is taking the printing industry by storm. It is quickly becoming one of the most popular technologies for textile printing compared to traditional printing methods.
